Main Specifications

Material:

Laminated Impact Acrylic

Finish:

High Gloss

Sheet Size:

24-1/8" x 48-3/4" // 613mm x 1238mm

Engraving Depth:

.012" // 0.30mm

Attributes:

View Physical Properties

Usage:

Interior Signage

Exterior Signage

Personal Identification

Control Panels

Safety Signage

Industrial Signage/Tags

Capabilities:

Saws

Drills

Shears

Laser Vector Cuts

Bevels

Heat Bendable

Screen Prints

Hot Stamps

Bonds

Physical Properties

IZOD Impact Strength

Notched at 73°F (22.78°C)
Value:1.10 ft lbs/in
ASTM Method:D-256

Tensile Strength

To break
Value:5,500 psi
ASTM Method:D-638
Elongation before break
Value:0.5
ASTM Method:D-638

Flexural Strength

Load to stretch outer surface 5%
Value:10,300 psi
ASTM Method:D-790

Specific Gravity

Value:1.15
ASTM Method:D-792

Rockwell Hardness

Value:M45
ASTM Method:D-785
View Main Specifications

Deflection Temperature

Temperature at which material deflects .010" (.254mm) at 264 psi
Value:175°F (79.44°C)
ASTM Method:D-648

Coefficient of Thermal Expansion

Inch/inch/°F
Value:0.000056
ASTM Method:D-696

Vicat Softening Point

Temperature for needle to penetrate 1mm (90F/hr, 2.2lbs)
Value:208F (97.78C)
ASTM Method:D-1525
Temperature for needle to penetrate 1mm (90F/hr, 11.0lbs)
Value:187F (86.11C)
ASTM Method:D-1525

Additional Information

Lacquers

Parchment/Black

422-8141-Ply1/16"

Red / White

422-6022-Ply1/16"
442-6022-Ply1/8"

Yellow / Black

422-7042-Ply1/16"
442-7042-Ply1/8"

Safety Yellow / Black

422-7942-Ply1/16"
442-7942-Ply1/8"

Bright Green / White

422-9322-Ply1/16"
442-9322-Ply1/8"

Teal / White

422-9622-Ply1/16"
442-9622-Ply1/8"

Blue / White

422-5122-Ply1/16"
442-5122-Ply1/8"

Sapphire / White

422-5622-Ply1/16"
442-5622-Ply1/8"

White / Red

422-2062-Ply1/16"
442-2062-Ply1/8"

White / Blue

422-2052-Ply1/16"
442-2052-Ply1/8"

White / Black

422-2042-Ply1/16"
442-2042-Ply1/8"

Black / White

422-4022-Ply1/16"
442-4022-Ply1/8"

Vintage Gold / Black

422-7742-Ply1/16"
442-7742-Ply1/8"

Vintage Silver / Black

422-3842-Ply1/16"
442-3842-Ply1/8"
